Slitting machine parameters Effective width: 1000mm/1300mm maximum diameter feed: Φ700mm Maximum winding diameter: 300mm Slitting width Slitting width: 10-1280mm Paper tube diameter: Φ25.4-Φ76.2mm Mechanical speed: 0-120m/min Cutting tool 0.2mm×22mm×60mm main unit Horsepower Horsepower 5hp/3.7kw Input Power supply 3P+1P, 380VAC, 5KVA functional features: 1. Simple operation control panel: control of all parts of this machine, centralized panel operation. 2. Three-stage length setting: Advanced three-stage indexing counting ensures precise winding length. 3. Automatic shaft exchange: After the winding operation is completed, the two shafts are automatically exchanged, which is simple to operate and highly efficient. 4. Labeling indication: The machine will automatically stop when the labeling length is reached, and a label mark indicating the film opening will be affixed to the platform. 5. Rear feeding method: Feeding is done from the rear side of the operating surface. It is equipped with rubber pressure wheels to reduce the noise of peeling the belt and ensure smooth discharging.
