| "Content |
Specification |
| "Size" |
64mm x 46mm x 17mm(1.8 "*2.5" *0.65 ") |
| Weight |
40g |
| "Network |
GSM/GPRS |
| Network frequency band |
850/900/1800/1900Mhz |
| "Chip" |
UBLOX chip |
| GPS sensitivity |
-159dBm |
| GPS accuracy |
5m |
| The first startup time |
Cold status 45s Warm status 35s Hot status 1s |
| Vehicle charging voltage |
12—24V input 5V output |
| Charging voltage of the handheld base |
110-220V input 5V output |
| Battery |
Youdaoplaceholder0 changeable 3.7V 800mAh Li-ion battery |
| Standby duration |
24hours |
| Storage temperature |
-40°C to +85°C |
| Working temperature |
-20°C to +55°C |
| Humidity |
5%--95% non-condensing |
Accessories
1 piece of GPS locator
Battery 1pcs
1 charging cable
Instruction Manual 1pcs
1 piece of packaging box
Optional: 1pcs battery, 1pcs charging base, 1pcs wall charger, 1pcs waterproof bag
Specifications:
Model: TK102B
Wireless network: GSM / GPRS
Frequency range: 850/900/1800 / 1900Mhz
GPS Module: Latest MT3336N chip
GPS sensitivity: -159 dBm
GPS accuracy: 5-15 m
GPS Start time: Restart approx. 45 s - Operation approx. 10s
External power supply: 12-24 V output
Stationary power supply: 110-240V input
Battery: 1000mAh
Operating temperature: from -20 ° C to + 55 ° C
Humidity: 5% - 95% (non-condensing)
Material: Plastic
Item Size: 46*12*65mm
Package Size: 122*103*53mm
