The profiled sheets rolled and formed by the roof panel forming machine are not only elegant and dignified but also beautiful and novel. Moreover, they have a smooth appearance, uniform corrugations, high utilization rate, great strength, high degree of production automation, low cost and long service life
Main technical parameters
Installation dimensions: 7000mm×1200mm×1000mm
2. Number of forming passes: 15
3. Roller material: 45# steel
4. Thickness of the electroplating layer on the roller: 0.05mm
5. Blade material: Cr12
6. Forming speed: 9-10m/min.
7. Electrical control system: Controlled by industrial computer PLC
8. Frequency converter: Accurate counting and anti-knife carrying function (optional)
9. Main unit power: 3kw
10. Hydraulic station power: 3kw
11. Sheet thickness: 0.2-0.7mm
12. Sheet unfolding width: 1000mm

The product is used for the roof production of various industrial plants, warehouses, etc. It features high wave peaks and great strength. The lap installation is safe and reliable, and it has strong waterproof, anti-typhoon and anti-explosion performance. The profiled sheets produced by this machine solve the roof leakage problem of conventional series profiled sheets. When combined with an arch machine, it can be used to make beamless arched roofs.
